Industrial by Design DisplayCORE®
12.3" Sunlight Readable Industrial Displays
"Industrial by DESIGN"
INDUSTRIAL GLASS with superior viewing angle IPS panels. Added to this are EXTREMELY WIDE Operating Temperatures, 1K Sunlight Readable HIGH Bright Backlights, Extremely Wide Operating Temp -30 to 85C and LONG Backlight Lifetime of 30,000 hours, HDMI Interface and USB HID GLASS Touch . This represents the state of the art for technology and design benefits for your next project! We couple this with our "INDUSTRIAL BY DESIGN" architecture for extended form factor support!
|
|||||||||
12.3" HDMI SUNLIGHT READABLE Display
1920x720 720P AHVA SUNLIGHT READABLE 1000 cd/m2(920*) ULTRA Wide Operating Temp -30 to 85C, 70K hour backlight and optional PCT USB Touch
An HDMI Extended Temperature (-30 to 85C) 1920x720 (HD capable) Wide Viewing Angle, EXTENDED Backlight Life OPTIONAL USB Glass PCT Screen embedded display.
 |
 |
 |
“INDUSTRIAL BY DESIGN” FEATURES
- Ultra WIDE EXTENDED Operating Temperature -30 to 85C
- WIDE Symmetric Viewing Angle of 85 degrees on all axis.
- Exceptional Contrast Ratio of 1000 typ
- HDMI Interface with through hole Soldered Connector for STRAIN RELIEF
- USB HID Meets Windows 10 requirements for human touch performance.
82-086-01 HDMI PCT Touch Display Datasheet
82-087-01 HDMI Display Datasheet
OVERVIEW a 12.3” AHVA TFT module with LED Backlight, HDM display interface and a USB PCT touch interface. This module supports 1920x720 display mode.
